Yamaha's DRIVE 4-Stroke and 48V golf cars are built to go wherever golf takes them. For additional information, visit Yamaha's new interactive website at www.discoverthedrive.com
Standard Specs
Overall Length 94.3 in. (2395mm)
Overall Width 47.2 in. (1200 mm)
Wheel Base
64.6 in. (1640 mm)
Min. Ground 4.3 in. (110 mm)
Seating Capacity 2
Maximum Speed 12~15 mph ( 19.3 ~ 24.1 km/h)
11.4 mph Reverse Speed
Max. Turning Radius 18.2 ft (2.8m)
Engine (DRIVE 4-Stroke only) Type of Engine: Yamaha low-emission, single-cylinder, overhead valve, four-stroke.
Total Displacement: 357
Output Rating: 11.4 HP @ 3500 RPM
Cooling System: Forced Cooling
Air Cleaner: Foam urethane pre-filter and automotive-type, high capacity pleated paper cartridge.
Lubrication System: Splash
Electric Motor/Speed Controller (DRIVE 48V only) Type of motor: Hitachi 48-Volt high-efficiency, shunt-wound motor with internal solid-state tachometer.
Output Rating: 2.6 kw (3.5 HP) for 30 minutes.
Speed Controller: Yamaha-built solid-state micro-processor with high-efficiency MOSFET switching. 270-amp armature output, 20 amp field output.
Additional Features found on all DRIVE Models
Front Suspension/Steering Front: Yamaha's Tru-Trak II fully independent automotive-style strut suspension.
Steering: Self-compensating double reduction helical rack -and-pinion, permanently lubricated with sealed, greasless tie-rod ends.
Rear Suspension Rear: Unit swing arm with coil springs over hydraulic shock absorbers.
Brakes Maintenance-free internal transaxle disc brake.
Frame Hybricore Chassis features a robotically welded automotive ladder-style frame mated to a polypropylene structural floor. Frame components are protected with a multi-step full-immersion phosphate treatment, electrodeposition epxy-based coating, and an electrostatically applied polyester/urethane powder topcoat.
Seating Seamless, fabric-backed vinyl bonded to pure, virgin foam contoured seat cushions and mated to a warp and moisture resistant polypropylene bottom, strengthened with plated steel inserts.
Body Custom formulated color matched thermoplastic olefin, painted with a two part topcoat of high luster automotive grade polyurethane.
Bumpers Yamaha's 5 mph energy absorbing front and rear bumpers are the same height to minimize damage to the body and the frame during a collision.
